Import the template, place your artwork, print, cut & assemble!
Do you want to try our design with this display? Add your logo, grab a board, print & cut… and its done!
Paper composite Board is a simple solution, lightweight & easy to produce! CARDBOARD.design Structural Templates are here for you!
FEATURES
• Add your artwork, print &cut
• Structural files in .AI, .PDF, .DXF
• Ready for Honeycomb 16 mm
• Easy to print and cut
• Quick set up in half minute
TECHNICAL INFORMATION
PLANO DIMENSION FOR 1UP
• PRINT DIMENSION: 1020x2040x16MM
• CUT DIMENSION: 1000x2020x16MM
RULE LENGTH
• THRU-CUT: 8341MM
MATERIALS NEEDED
• HONEYCOMB BOARD 16MM (such as Reboard, Beelite, X-Board…)
• BOARD QUANTITY: X1
• MINIMUM BOARD SIZE: 1200x2400MM
• MINIMUM BOARD QUANTITY: 1X WITH 1200x2400MM
SUITABLE FOR
• WIDE PRINTER UV, LED, SCREEN-PRINTING…
• FLATBED CUTTER
• TESTED ON ZUND G3 ON RE-BOARD (ICB) 16MM & BEELITE (HCB) 16MM
FILES INCLUDED
PRODUCTION FILES
• 1UP FILES IN AI, PDF, DXF
• NESTED FILES 1200X2400MM IN AI, PDF, DXF
PREVIEW FILES
• 3D AR MODELS FOR ADOBE AERO
• 3D MODELS IN OBJ
• DIMENSION FILES FOR 3D MOCKUP
• PROTOTYPES & PRODUCT PICTURES
TECHNICAL DATA
• 1 SUMMARY PDF WITH INFORMATION & SETUP
AR PREVIEW
Scan the QRCODE and view the product in AR in the real world and real dimension.
Click above to download it!
